Level Luffing Crane
Description
Open+
Close-

As the benchmark of China's crane industry, Weihua has designed and produced China's largest 80-ton four-link gantry crane and designed and produced a single-boom gantry crane with a maximum of 300 tons.

MQ portal crane is widely used in ports, stations, and storage yards, which can efficiently carry out operation of load, unload and transship to speed up the turn around of ships and vehicles. Advantages of port portal crane: good performance, beautiful exterior, efficient work, compact structure, running balanced, comfortable operation, safe&reliable, convenient for maintenance. Port portal crane can be used at limited space in ports to load and unload cargo on ships, and leave considerable room for vehicles to pass through, especially applies to universal ports.

Since 1988, we have 34 years of experience in the crane industry, our gantry cranes have been the No. 1 sales in China for 14 consecutive years, and through our high-quality products and excellent service, we provide crane equipment to various industries. It is based on our comprehensive strength that we have the capability of short delivery cycle and fast delivery.

Whether you choose a single-arm portal crane or a double-arm portal crane, you can consult our experts to provide you with the best solution, we have a technical team of 1,000 people and 7,000 employees to serve you .

Features
Open+
Close-

1. The sling can be grappled, with good adaptability and a wide range of applications;

2. Optimized four-bar linkage mechanism, precise luffing;

3. 360° rotation, wide working range;

4. PLC control, AC frequency conversion speed regulation, stable and reliable operation;

5. Remote control can be provided as needed;

6. There are sufficient protective devices, communication and lighting systems.

Type

Lifting

Capacity (t)

Height Height Gauge×base Lifting Speed

Max Wheel

Load (KN)

Installed

Capacity (KW)

Match

Ship (/DWT)

Max (m) Min (m) above rail (m) below rail (m) (m) Lifting (m/min) Amplitute (m/min) Rotation (m/min) Crane (m/min)
MQ525 5 25 8 12 9 10.5× 40 24 1.5 25 180 280 19000
10.5
MQ535 5 33 10 15 9 10.5× 50 40 1.5 25 210 300 30000
10.5
MQ1025 10 25 8 15 9 10.5× 50 50 1.5 25 220 330 19000
10.5
MQ1033 10 33 10 20 12 10.5× 50 40 1.4 25 185 345 30000
10.5
MQ1625 16 25 9 20 12 10.5× 50 40 1.5 25 240 325 19000
10.5
MQ1633 16 33 10 28 15 10.5× 60 40 1.5 25 250 345 30000
10.5
MQ2533 25 33 10 28 15 10.5× 60 50 1.5 25 260 435 30000
10.5
MQ4033 40 33 10 28 16 10.5× 50 50 1.41 25 260 560 30000
10.5
S4070 40 65 24 45 13 10.5× 15 17 0.26 26 260 400 100000
K10 70 29 45 13   18.5
S5035 50 35 12 40 0 10.5× 7.5 12.8 0.4 25 250 250 30000
K10 38 14 40 0   12
S8035 80 35 12 40   12× 6 12.8 0.4 25 250 320 30000
K10           10.5
